Scrawl-canvas v8 - Canvas test 043

Test various clipping strategies

To note: Javascript is not running in this browser environment. Our apologies, but this demo has not yet been updated to support progressive enhancement.

Applying more than one clipped region to a scene, using Groups to separate them:

Generate and use Picture entitys from clipped scenes rendered in their own cells:

Note that Label entitys cannot clip to the letters.
For these, we have to use alternative solutions.

Emulate clipping to a Label entity using a composite scene rendered in its own cell:

... Once we have the clipped text in its own cell, we could then generate a Picture entity from it (not tested in this demo).

Test purpose

A set of three canvases to test clipping, and clip-to-text emulation.
For all canvases, the shape/label entitys should clip the image; as they rotate, the image they contain should rotate with them.
All entitys should be draggable, including the Cell entity (pivoted to a draggable Block entity)

Touch test: should work as expected - note that for some reason the canvas needs tapping before it will allow drag to happen on it (needs investigating!)
